Data quality adjustment¶

Some indicators are excluded from all adjustments due to their sensitive nature:

EXCLUDED_FROM_ADJUSTMENT <- c("u5_deaths", "maternal_deaths", "neonatal_deaths")

Rationale: Death counts should not be smoothed or imputed as they represent discrete events that may have genuine temporal variation. Adjusting these could mask important epidemiological patterns or outbreak signals.

Indicators are also automatically excluded from adjustment if they have zero observations above 100 across the entire dataset. This prevents meaningless statistical adjustment on indicators with consistently low counts.

Exclusion logic:

volume_check <- raw_data[, .(
  above_100 = sum(count > 100, na.rm = TRUE),
  total = .N
), by = indicator_common_id]

no_outlier_adj <- volume_check[above_100 == 0, indicator_common_id]

This information is saved to M2_low_volume_exclusions.csv for transparency.

The module uses a 6-month window for all rolling averages. This choice balances:

Advantages:

• Captures medium-term trends
• Reduces impact of short-term fluctuations
• Sufficient data points for stable averages
• Works well for both stable and seasonal indicators

Trade-offs:

• May not capture rapid changes in service delivery
• Could over-smooth in cases of genuine programmatic shifts
• Requires at least 6 valid observations for optimal centered average

The module requires three input files from previous processing steps:

Raw HMIS Data (hmis_ISO3.csv):

facility_id | admin_area_1 | admin_area_2 | admin_area_3 | period_id | indicator_common_id | count
------------|--------------|--------------|--------------|-----------|---------------------|-------
FAC001      | ISO3         | Province_A   | District_A   | 202301    | anc1                | 145
FAC001      | ISO3         | Province_A   | District_A   | 202302    | anc1                | 152
FAC001      | ISO3         | Province_A   | District_A   | 202303    | anc1                | 890  # Outlier

Outlier flags (M1_output_outliers.csv):

facility_id | indicator_common_id | period_id | outlier_flag
------------|---------------------|-----------|-------------
FAC001      | anc1                | 202301    | 0
FAC001      | anc1                | 202302    | 0
FAC001      | anc1                | 202303    | 1           # Flagged as outlier

Completeness flags (M1_output_completeness.csv):

facility_id | indicator_common_id | period_id | completeness_flag
------------|---------------------|-----------|------------------
FAC001      | anc1                | 202301    | 1             # Complete
FAC001      | anc1                | 202302    | 0             # Incomplete
FAC001      | anc1                | 202303    | 1             # Complete

The module generates four output files:

Facility-Level Output (M2_adjusted_data.csv):

facility_id | admin_area_2 | admin_area_3 | period_id | indicator_common_id | count_final_none | count_final_outliers | count_final_completeness | count_final_both
------------|--------------|--------------|-----------|---------------------|------------------|----------------------|--------------------------|------------------
FAC001      | Province_A   | District_A   | 202301    | anc1                | 145              | 145                  | 145                      | 145
FAC001      | Province_A   | District_A   | 202302    | anc1                | 152              | 152                  | 148                      | 148
FAC001      | Province_A   | District_A   | 202303    | anc1                | 890              | 148                  | 890                      | 148

Each count_final_* column represents a different adjustment scenario:

• count_final_none: No adjustments applied (original values)
• count_final_outliers: Only outlier adjustment applied
• count_final_completeness: Only completeness adjustment applied
• count_final_both: Both outlier and completeness adjustments applied

The module depends on the following R packages:

• data.table - High-performance data manipulation and aggregation
• zoo - Rolling window calculations (frollmean for rolling averages)
• lubridate - Date handling and manipulation

Core function that implements the adjustment logic for a single scenario.

Purpose:

Replaces outlier and/or incomplete values using rolling averages and historical patterns.

Parameters:

• raw_data (data.table): Original HMIS data with service counts
• completeness_data (data.table): Completeness flags from Module 1
• outlier_data (data.table): Outlier flags from Module 1
• adjust_outliers (logical): Whether to apply outlier adjustment
• adjust_completeness (logical): Whether to apply completeness adjustment

Returns:

data.table with adjusted values in count_working column and adjustment metadata

Key operations:

1. Merges input datasets by facility_id, indicator_common_id, and period_id
2. Converts period_id to dates for temporal ordering
3. Calculates rolling averages (centered, forward, backward) for valid values
4. Applies adjustment hierarchy based on data availability
5. Tracks adjustment method used for each replaced value

Wrapper function that runs adjustments across all four scenarios.

Purpose:

Applies the adjustment logic under different combinations of outlier and completeness adjustments.

Parameters:

• raw_data (data.table): Original HMIS data
• completeness_data (data.table): Completeness flags
• outlier_data (data.table): Outlier flags

Returns:

data.table with four count_final_* columns, one per scenario

Scenarios processed:

1. none: No adjustments (baseline)
2. outliers: Outlier adjustment only
3. completeness: Completeness adjustment only
4. both: Sequential outlier then completeness adjustment

Processing logic:

• Calls apply_adjustments() once per scenario
• Preserves original values for excluded indicators (deaths)
• Merges all scenario results into a single wide-format table

Outlier adjustment is applied to any facility-month value flagged in Module 1 (outlier_flag == 1). The goal is to replace these outlier values using valid historical data from the same facility and indicator.

Statistical approach:

Rolling averages are used to estimate expected values. A rolling average (also called moving average) is the mean of a set of time periods surrounding the target period. This technique smooths short-term fluctuations and highlights longer-term trends.

Valid values definition:

Only values meeting ALL of the following criteria are used in calculations:

• !is.na(count) (non-missing)
• outlier_flag == 0 (not flagged as outlier)

Implementation:

The module uses frollmean() from the zoo package for efficient rolling calculations:

data_adj[, valid_count := fifelse(outlier_flag == 0L & !is.na(count), count, NA_real_)]
data_adj[, `:=`(
  roll6   = frollmean(valid_count, 6, na.rm = TRUE, align = "center"),
  fwd6    = frollmean(valid_count, 6, na.rm = TRUE, align = "left"),
  bwd6    = frollmean(valid_count, 6, na.rm = TRUE, align = "right"),
  fallback= mean(valid_count, na.rm = TRUE)
), by = .(facility_id, indicator_common_id)]

The adjustment process follows this hierarchical order (stopping at the first available method):

1. Centered 6-Month Average (roll6)

   • Uses the three months before and three months after the outlier month
   • Provides a balanced average based on nearby trends
   • Applied when enough valid values exist on both sides of the month
   • Method tag: roll6

2. Forward-Looking 6-Month Average (fwd6)

   • Used if the centered average can't be calculated (e.g. early in the time series)
   • Takes the average of the next six valid months
   • Method tag: forward

3. Backward-Looking 6-Month Average (bwd6)

   • Used if neither roll6 nor fwd6 are available
   • Takes the average of the six most recent valid months before the outlier
   • Method tag: backward

4. Same month from previous year

   • If no valid 6-month average exists, the value from the same calendar month in the previous year is used (e.g., Jan 2023 for Jan 2024)
   • Only applied if that previous value is valid (not an outlier, and > 0)
   • Particularly useful for seasonal indicators (e.g., malaria, respiratory infections)
   • Method tag: same_month_last_year
   • Implementation:

   data_adj[, `:=`(mm = month(date), yy = year(date))]
   data_adj <- data_adj[, {
     for (i in which(outlier_flag == 1L & is.na(adj_method))) {
       j <- which(mm == mm[i] & yy == yy[i] - 1 & outlier_flag == 0L & !is.na(count))
       if (length(j) == 1L) {
         count_working[i] <- count[j]
         adj_method[i]    <- "same_month_last_year"
         adjust_note[i]   <- format(date[j], "%b-%Y")
       }
     }
     .SD
   }, by = .(facility_id, indicator_common_id)]


5. Mean of All Historical Values (Fallback)

   • If all previous methods fail, the mean of all valid historical values for that facility-indicator is used
   • Provides a facility-specific baseline when no temporal pattern is available
   • Method tag: fallback

Edge case:

If no valid replacement can be found from any of these methods, the original outlier value is retained.

Completeness adjustment is applied to any facility-month where:

• The month is flagged as incomplete (completeness_flag != 1) in Module 1, OR
• The value is missing (is.na(count_working))

Statistical approach:

The same rolling average methodology is applied, but the definition of "valid values" differs slightly:

Valid values for completeness adjustment:

• !is.na(count_working) (non-missing, possibly already adjusted for outliers)
• outlier_flag == 0 (not flagged as outlier in original data)

Key difference from outlier adjustment:

• Completeness adjustment can use values that were already adjusted for outliers (when scenarios include both adjustments)
• No same-month-last-year method is used (only rolling averages and fallback)

Implementation:

data_adj[, valid_count := fifelse(!is.na(count_working) & outlier_flag == 0L, count_working, NA_real_)]
data_adj[, `:=`(
  roll6   = frollmean(valid_count, 6, na.rm = TRUE, align = "center"),
  fwd6    = frollmean(valid_count, 6, na.rm = TRUE, align = "left"),
  bwd6    = frollmean(valid_count, 6, na.rm = TRUE, align = "right"),
  fallback= mean(valid_count, na.rm = TRUE)
), by = .(facility_id, indicator_common_id)]

The replacement follows this hierarchical order:

1. Centered 6-Month Average (roll6)

   • Uses three valid months before and after the missing or incomplete month
   • Preferred method when sufficient surrounding data exists
   • Method tag: roll6

2. Forward-Looking 6-Month Average (fwd6)

   • Used if the centered average cannot be calculated (e.g., at start of time series)
   • Method tag: forward

3. Backward-Looking 6-Month Average (bwd6)

   • Used if no centered or forward-looking values are available (e.g., at end of time series)
   • Method tag: backward

4. Mean of All Historical Values (Fallback)

   • If no rolling averages can be calculated, uses the mean of all valid values for that facility-indicator
   • Provides a facility-specific baseline
   • Method tag: fallback

Edge case:

If no valid replacement is found, the value remains missing (NA).

The module processes all four adjustment scenarios simultaneously using the apply_adjustments_scenarios() function:

Scenario 1: None (count_final_none)

• adjust_outliers = FALSE, adjust_completeness = FALSE
• Original raw data with no modifications
• Serves as baseline for comparison

Scenario 2: Outliers (count_final_outliers)

• adjust_outliers = TRUE, adjust_completeness = FALSE
• Only outlier values are replaced
• Missing/incomplete values remain as-is
• Use case: When completeness is high but outliers are a concern

Scenario 3: Completeness (count_final_completeness)

• adjust_outliers = FALSE, adjust_completeness = TRUE
• Only missing/incomplete values are imputed
• Outliers are retained in the data
• Use case: When data quality is good but reporting is sporadic

Scenario 4: Both (count_final_both)

• adjust_outliers = TRUE, adjust_completeness = TRUE
• Sequential processing: Outliers adjusted first, then completeness
• Most comprehensive adjustment
• Use case: When both data quality issues are prevalent

Processing order for "Both" scenario:

1. Outlier adjustment creates count_working with outliers replaced
2. Completeness adjustment then operates on count_working, using the already-adjusted values
3. This ensures completeness imputation uses cleaned (non-outlier) values when available

Important:

After scenario-specific adjustments, excluded indicators (deaths) are reset to their original values:

dat[indicator_common_id %in% EXCLUDED_FROM_ADJUSTMENT, count_working := count]

All geographic aggregations use simple sums:

sum(count_final_both, na.rm = TRUE)

Rationale:

• Service volumes are additive (e.g., total deliveries = sum of facility deliveries)
• Missing values (NA) are treated as zero in aggregation
• Consistent with standard HMIS reporting practices

Caution:

If many facilities have NA values after adjustment, subnational/national totals may be underestimated. The count_final_none scenario provides a reference point for assessing impact.

The module applies na.rm = TRUE in all rolling calculations:

frollmean(valid_count, 6, na.rm = TRUE, align = "center")

Implication:

Rolling averages are calculated from available valid values only. If fewer than 6 values exist, the average is computed from whatever is available. If no valid values exist, the result is NA.

Scenario:

A facility reports an unusually high first antenatal care visit (ANC1) count in March 2023.

Data:

period_id | count | outlier_flag | Surrounding valid values
----------|-------|--------------|-------------------------
202301    | 145   | 0            | valid
202302    | 152   | 0            | valid
202303    | 890   | 1            | OUTLIER
202304    | 148   | 0            | valid
202305    | 155   | 0            | valid
202306    | 147   | 0            | valid

Adjustment calculation (centered 6-month average):

• Valid values: [145, 152, 148, 155, 147] (excludes outlier 890)
• Average: (145 + 152 + 148 + 155 + 147) / 5 = 149.4
• Adjusted value: 149.4

Method used:

roll6

Scenario:

A facility fails to report malaria tests in February 2023.

Data:

period_id | count | completeness_flag | Surrounding valid values
----------|-------|-------------------|-------------------------
202301    | 45    | 1                 | valid
202302    | NA    | 0                 | INCOMPLETE
202303    | 48    | 1                 | valid
202304    | 52    | 1                 | valid
202305    | 50    | 1                 | valid

Adjustment calculation (centered 6-month average):

• Valid values: [45, 48, 52, 50, ...]
• Average: 48.75 (using available surrounding months)
• Imputed value: 48.75

Method used:

roll6

Scenario:

Malaria cases show strong seasonality, and a June 2023 outlier needs adjustment.

Data:

period_id | count | outlier_flag | Notes
----------|-------|--------------|-------
202206    | 234   | 0            | June 2022 (valid)
202306    | 1850  | 1            | June 2023 (OUTLIER)

Adjustment logic:

1. Centered, forward, and backward rolling averages unavailable (insufficient data)
2. Same-month-last-year method activated
3. June 2022 value = 234 (valid)
4. Adjusted value: 234

Method used:

same_month_last_year

Facility:

FAC001

Indicator:

Institutional deliveries

Period:

Q1 2023

Original data:

Month    | Count | Outlier? | Complete?
---------|-------|----------|----------
Jan 2023 | 78    | No       | Yes
Feb 2023 | 450   | Yes      | Yes       # Outlier
Mar 2023 | NA    | -        | No        # Incomplete

Scenario results:

*Adjusted using rolling average

**Imputed using rolling average

Interpretation:

• None: Raw data with obvious issues
• Outliers: February corrected, but March remains missing
• Completeness: March filled in, but February outlier retained
• Both: Most complete and clean dataset

Subnational aggregation code:

adjusted_data_admin_area_final <- adjusted_data_export[
  ,
  .(
    count_final_none         = sum(count_final_none,         na.rm = TRUE),
    count_final_outliers     = sum(count_final_outliers,     na.rm = TRUE),
    count_final_completeness = sum(count_final_completeness, na.rm = TRUE),
    count_final_both         = sum(count_final_both,         na.rm = TRUE)
  ),
  by = c(geo_admin_area_sub, "indicator_common_id", "period_id")
]

National aggregation code:

adjusted_data_national_final <- adjusted_data_export[
  ,
  .(
    count_final_none         = sum(count_final_none,         na.rm = TRUE),
    count_final_outliers     = sum(count_final_outliers,     na.rm = TRUE),
    count_final_completeness = sum(count_final_completeness, na.rm = TRUE),
    count_final_both         = sum(count_final_both,         na.rm = TRUE)
  ),
  by = .(admin_area_1, indicator_common_id, period_id)
]

Issue 1: All values remain unadjusted

Possible causes:

• Indicator is in the excluded list (deaths)
• Indicator flagged as low-volume
• No outlier or completeness flags in input data

Solution:

Check M2_low_volume_exclusions.csv and verify Module 1 outputs contain flags

Issue 2: Adjusted values seem unreasonable

Possible causes:

• Insufficient valid historical data for rolling averages
• Genuine program changes being smoothed out
• Seasonal patterns not captured by 6-month window

Solution:

• Review facility-specific time series plots
• Consider using "outliers only" scenario if completeness is good
• Validate against program implementation records

Issue 3: Many NA values after adjustment

Possible causes:

• Facility has very sparse data
• No valid values available for any adjustment method
• Early months in time series lack historical data

Solution:

• Expected for facilities with limited reporting history
• Consider facility-level data quality filtering
• National/subnational aggregates will sum available values

Issue 4: Subnational/national totals don't match expectations

Possible causes:

• NA values treated as zero in aggregation
• Different scenarios produce different totals
• Low reporting completeness overall

Solution:

• Compare count_final_none vs count_final_both to assess adjustment impact
• Review Module 1 completeness statistics
• Consider data quality threshold for inclusion

The module includes several quality checks:

1. Low volume exclusions: Automatically identifies and excludes indicators with zero high-value observations
2. Adjustment tracking: Counts and reports number of values adjusted by each method
3. Excluded indicators: Ensures deaths are never adjusted
4. Console logging: Provides detailed progress and summary statistics

Example console output:

Running adjustments...
 -> Adjusting outliers...
     Roll6 adjusted: 1,245
     Forward-filled: 89
     Backward-filled: 67
     Same-month LY: 34
     Fallback mean: 12
 -> Adjusting for completeness...
     Roll6 filled: 2,103
     Forward-filled: 234
     Backward-filled: 178
     Fallback mean: 45

After running this module, consider:

1. Compare scenarios: Examine differences between count_final_none and count_final_both
2. Review exclusions: Check M2_low_volume_exclusions.csv for unexpected indicators
3. Aggregate analysis: Ensure subnational and national totals are reasonable
4. Temporal plots: Visualize trends before/after adjustment to identify over-smoothing
5. Facility-level spot checks: Review adjustments for a sample of facilities

1. Rolling windows assume stability: Adjustments work best when service delivery is relatively stable. Genuine program changes (e.g., new campaigns) may be incorrectly smoothed.

2. No adjustment uncertainty: The module provides point estimates without confidence intervals. Adjusted values should be treated as estimates.

3. Facility-specific adjustments: No cross-facility borrowing of information. Facilities with very sparse data may have unstable adjustments.

4. Seasonal patterns: While same-month-last-year helps, strong within-year seasonality may not be fully captured by 6-month windows.

5. NA treatment in aggregation: Missing values are treated as zero when summing to higher geographic levels, which may underestimate totals if missingness is high.
